be quiet! Silent Base 601 ATX Mid Tower Black / Silver with Tempered Glass Side Panel and USB 3.2 Gen 1 Type-A USB 2.0 Type-A
be quiet! · case

be quiet! Silent Base 601 ATX Mid Tower Black / Silver with Tempered Glass Side Panel and USB 3.2 Gen 1 Type-A USB 2.0 Type-A

ATX/MATX/ITX · 3× 3.5″

Formato
ATX / MATX / ITX
Comprimento máx. da GPU
449 mm
Altura máx. do cooler
185 mm
Baias de 3,5″
3

Vizinhança

Vizinhos top por relação — clica para abrir

be quiet! Silent Base 601 ATX Mid Tower Black / Silver with Tempered Glass Side Panel and USB 3.2 Gen 1 Type-A USB 2.0 Type-A
Aponte para uma peça para ver o que é — clique para abri-la

Especificações

Dados do catálogo

Fonte: OpenDB
Color
BLACK, GREY
Side panel
Tempered Glass
Form factor
ATX Mid Tower
Expansion slots
7
Front panel USB
USB 3.2 Gen 1 Type-A USB 2.0 Type-A
Internal 3.5 bays
3
Max video card length
449 mm
Has transparent side panel
Sim
Supported motherboard form factors
ATX, Micro ATX, Mini-ITX

Dados do fabricante

Fonte: Icecat
Type
PC
Depth
532 mm
Width
240 mm
Height
514 mm
Weight
11.2 kg
Material
Acrylonitrile butadiene styrene (ABS), SECC, Tempered glass
Audio input
Yes
Form factor
Midi Tower
Side window
Yes
Audio output
Yes
Certification
CE, RoHS
Fan connector
3-pin
Mostrar mais 37 especificações
Package depth
566 mm
Package width
325 mm
Led indicators
HDD
Package height
615 mm
Package weight
13.2 kg
Product colour
Black, Silver
Maximum airflow
61.2 cfm
Anti dust filter
Yes
Fan rated current
0.12 A
Maximum psu length
28.8 cm
Built in speaker(s)
No
Number of 2.5" bays
6
Number of 3.5" bays
3
Rear fans installed
1x 140 mm
Supported HDD sizes
2.5,3.5"
Front fans installed
1x 140 mm
Fan power consumption
1.44 W
Power supply included
No
Card reader integrated
No
USB 2.0 ports quantity
1
Tempered glass panel(s)
Yes
Noise level (high speed)
18.8 dB
Maximum CPU cooler height
18.5 cm
Number of expansion slots
9
Harmonized system (hs) code
84733080
Maximum graphics card length
44.9 cm
Top fans diameters supported
120,140 mm
Top radiator sizes supported
120,240,360 mm
Rear radiator sizes supported
120,140 mm
Front fans diameters supported
120,140 mm
Front radiator sizes supported
120,140,240,280,360 mm
Tempered glass panel thickness
4 mm
Number of top fans supported (max)
3
Supported motherboard form factors
ATX, EATX, micro ATX, Mini-ITX
Supported power supply form factors
ATX, PS2
Number of front fans supported (max)
2
USB 3.2 gen 1 (3.1 gen 1) type a ports quantity
2
