ASUS ROG STRIX X870E-E GAMING WIFI

Name: ASUS ROG STRIX X870E-E GAMING WIFI
Brand: ASUS

AMD X870E · ATX · 5× M.2

Socket

AM5

Chipset

AMD X870E

Formato

ATX

Memoria

DDR5

Memoria max.

256 GB

Slot M.2

Vicini top per relazione — clicca per aprire

Punta un componente per vedere cos'è — clicca per aprirlo

Fonte: OpenDB

Mostra altre 29 specifiche

M.2 slots 4: Key M · 2280 · PCIe 4.0 x4
M.2 slots 5: Key M · 2280 · PCIe 4.0 x4
PCIe slots 1: Gen 5.0 · Lanes 16 · Quantity 1
PCIe slots 2: Gen 4.0 · Lanes 4 · Quantity 1
ECC support: Sì
Fan headers · Pump: 1
Fan headers · CPU fan: 1
Fan headers · CPU opt: 1
Fan headers · Case fan: 5
Form factor: ATX
RGB headers · ARGB 5v: 3
USB headers · USB 2.0: 3
USB headers · USB 3.2 gen 1: 2
USB headers · USB 3.2 gen 2x2: 1
Raid support: Sì
Bios features · Flashback: Sì
Bios features · Clear cmos: Sì
Other headers · Temperature sensor: 1
Storage devices · SATA 6 gb s: 4
Back panel ports: 2 x USB4® (40Gbps) ports (2 x USB Type-C®), 1 x USB 20Gbps port (1 x USB Type-C® with up to 30W PD Fast-charge), 10 x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C®), 1 x HDMI™ port, 1 x Wi-Fi Module, 1 x Realtek 5Gb Ethernet, 2 x Gold-plated audio jacks, 1 x Optical S/PDIF out port, 1 x BIOS FlashBack™ button, 1 x Clear CMOS button
Onboard ethernet 1: 5 Gb/s · Realtek
Power connectors · CPU power: 8-pin, 8-pin
Power connectors · Main power: 24-pin
Front panel headers · HDD led: Sì
Front panel headers · Power led: Sì
Front panel headers · Power button: Sì
Front panel headers · Reset button: Sì
Wireless networking: Wifi 7
Back connect connectors: No
