StarTech ST1000SPEX Gigabit Ethernet PCIe x1
StarTech · network

StarTech ST1000SPEX Gigabit Ethernet PCIe x1

1GbE · 1× ports

Speed
1 GbE
Ports
1

Neighbourhood

Top neighbours grouped by relation — click to open

StarTech ST1000SPEX Gigabit Ethernet PCIe x1
Point at a part to see what it is — click to open it

Specifications

Manufacturer data

Source: Icecat
Depth
120 mm
Width
21 mm
Height
92.5 mm
Weight
45 g
Chipset
Realtek RTL8111B
Internal
Yes
I/o ports
1x RJ45 FM
Interface
Ethernet
Full duplex
Yes
Ethernet lan
Yes
Link/act led
Yes
Certification
CE, FCC, ROHS
Show 18 more specs
Package depth
175 mm
Package width
140 mm
Auto mdix ieee
Yes
Host interface
PCI Express
Package height
30 mm
Package length
17.5 cm
Ports quantity
1
Product colour
Black
Dimensions (wxdxh)
21 x 120 x 92.5 mm
Networking features
Gigabit Ethernet
Jumbo frames support
Yes
Storage temperature (t t)
20 - 70 °C
Maximum data transfer rate
2000 Mbit/s
Operating temperature (t t)
0 - 50 °C
Compatible operating systems
Windows 2000, XP(32/64bit), Server 2003(32/64bit), Vista(32/64bit), 7(32/64bit), Server 2008 R2 Linux
Compliance industry standards
IEEE 802.3
Supported data transfer rates
10/100/1000 Mbps
Other network protocols supported
CSMA/CD
