Seagate IronWolf Pro 20TB HDD 3.5" SATA

3.5 HDD · 20 TB · NAS-rated

Capacity

20 TB

Type

3.5 HDD

Interface

SATA 6.0 Gb/s

Form factor

3.5"

Neighbourhood

Top neighbours grouped by relation — click to open

Seagate IronWolf Pro 20TB HDD 3.5" SATA

Point at a part to see what it is — click to open it

Specifications

Catalog data

Source: OpenDB

NVMe: No
Type: HDD
Capacity: 20000 GB
Interface: SATA 6.0 Gb/s
Form factor: 3.5"
Storage type: HDD

Manufacturer data

Source: Icecat

Type: HDD
Depth: 147 mm
Width: 101.8 mm
Height: 26.1 mm
Weight: 670 g
HDD size: 3.5"
HDD speed: 7200 RPM
HDD capacity: 20 TB
Component for: NAS
Operating shock: 40 G
Start up current: 2 A
Operating voltage: 5 / 12 V

Show 17 more specs

Noise level (idle): 20 dB
Non operating shock: 200 G
Workload rate limit: 550 TB/year
Non operating vibration: 2.27 G
Power consumption (off): 1 W
Power consumption (idle): 5.5 W
Storage drive buffer size: 256 MB
Storage temperature (t t): -40 - 70 °C
HDD interface transfer rate: 6 Gbit/s
HDD sustained transfer rate: 285 MiB/s
Mean time to failure (mttf): 2500000 h
Operating temperature (t t): 0 - 65 °C
Power consumption (standby): 1 W
Power consumption (typical): 7.7 W
Mean time between failures (mtbf): 2500000 h
Rotational vibration (rv) sensors: Yes
Uncorrectable bit error rate (uber): < 1 per 10^15 bits read
