be quiet! Straight Power 11 550W Fully Modular 80+ Gold
be quiet! · psu

be quiet! Straight Power 11 550W Fully Modular 80+ Gold

550 W · gold · modularused in 48 published build(s)

Wattage
550 W
Efficiency
80+ gold
Modular
full
Form factor
ATX

Neighbourhood

Top neighbours grouped by relation — click to open

be quiet! Straight Power 11 550W Fully Modular 80+ Gold
Point at a part to see what it is — click to open it

Specifications

Catalog data

Source: OpenDB
Length
160 mm
Fanless
No
Modular
Full
Wattage
550 W
Connectors · SATA
9
Connectors · Eps 8 pin
1
Connectors · Atx 24 pin
1
Connectors · Molex 4 pin
6
Connectors · PCIe 6 plus 2 pin
2
Form factor
ATX
Efficiency rating
80+ Gold

Manufacturer data

Source: Icecat
Depth
160 mm
Width
150 mm
Height
86 mm
Manual
Yes
Weight
1.51 kg
Purpose
PC
Hold time
18.9 ms
Efficiency
93%
Peak power
600 W
Atx version
2.4
Eps version
2.92
Silent mode
Yes
Show 53 more specs
Total power
550 W
Cabling type
Fully-Modular
Fan diameter
13.5 cm
Illumination
No
Power factor
0.99
Certification
CE, FCC, TÜV, cTUVus, RCM, BSMI, CU
Input current
8 A
On/off switch
Yes
Package depth
328 mm
Package width
248 mm
Number of fans
1 fan(s)
Package height
102 mm
Package weight
2.76 kg
Product colour
Black
Screws included
Yes
Ac input voltage
100 - 240 V
Cable management
Yes
Ac input frequency
50 - 60 Hz
Bearing technology
FDB
Cable ties included
Yes
Combined power (+5v)
130 W
80 plus certification
80 PLUS Gold
Combined power (+12v)
549.6 W
Combined power ( 12v)
3.6 W
Combined power (+3.3v)
130 W
Combined power (+5vsb)
15 W
CPU power cable length
70 cm
Compliance certificates
RoHS
SATA power cable length
550 mm
Max output current (+5v)
24 A
Max output current ( 12v)
0.3 A
Power protection features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Max output current (+12v1)
18 A
Max output current (+12v2)
18 A
Max output current (+12v3)
20 A
Max output current (+12v4)
20 A
Max output current (+3.3v)
24 A
Max output current (+5vsb)
3 A
Floppy disk drive connector
Yes
Harmonized system (hs) code
84733020
Motherboard power connector
20+4 pin ATX
Sustainability certificates
ENERGY STAR
CPU power connector (4+4 pin)
Yes
Noise level (quiet mode, 50%)
9.46 dB
Motherboard power cable length
60 cm
Pci express power cable length
60 cm
Noise level (silent mode, <30%)
9.02 dB
Number of pata power connectors
3
Number of SATA power connectors
9
Noise level (full load mode, 100%)
17.22 dB
Power factor correction (pfc) type
Active
Power supply unit (psu) form factor
ATX
Pci express power connectors (6+2 pin)
2

Builds that use it

48
