ASRock Z890 Taichi
ASRock · motherboard

ASRock Z890 Taichi

Intel Z890 · ATX · 12× M.2

Socket
LGA 1851
Chipset
Intel Z890
Form factor
ATX
Memory
DDR5
Max memory
256 GB
M.2 slots
12

Neighbourhood

Top neighbours grouped by relation — click to open

ASRock Z890 Taichi
Point at a part to see what it is — click to open it

Specifications

Catalog data

Source: OpenDB
Audio · Chipset
Realtek
Audio · Channels
7.1
Color
BLACK, GOLD
Memory · Max
256 GB
Memory · Slots
4
Memory · RAM type
DDR5
Socket
LGA 1851
Chipset
Intel Z890
M.2 slots 1
Key M · 2280 · PCIe 4.0 x4
M.2 slots 2
Key M · 2260-2280 · PCIe 4.0 x4
M.2 slots 3
Key M · 2280 · PCIe 4.0 x4
M.2 slots 4
Key M · 2230-2242 · PCIe 4.0 x4
Show 21 more specs
M.2 slots 5
Key M · 2280 · PCIe 4.0 x4
M.2 slots 6
Key M · 2260-2280 · PCIe 4.0 x4
M.2 slots 7
Key M · 2280 · PCIe 4.0 x4
M.2 slots 8
Key M · 2260-2280 · PCIe 4.0 x4
M.2 slots 9
Key M · 2280 · PCIe 4.0 x4
M.2 slots 10
Key M · 2260-2280 · PCIe 4.0 x4
M.2 slots 11
Key M · 2280 · PCIe 4.0 x4
M.2 slots 12
Key E · 2280 · PCIe 4.0 x4
PCIe slots 1
Gen 4.0 · Lanes 16 · Quantity 2
ECC support
No
Form factor
ATX
USB headers · USB 2.0
2
USB headers · USB 3.2 gen 1
2
USB headers · USB 3.2 gen 2x2
1
Raid support
Yes
Bios features · Flashback
No
Bios features · Clear cmos
No
Storage devices · SATA 6 gb s
4
Back panel ports
1 x 2.5 Gb/s (Realtek Dragon RTL8125BG) 1 x 5 Gb/s (Realtek 8126)
Onboard ethernet 1
2.5 Gb/s · Realtek Dragon RTL8125BG
Back connect connectors
No
